1 Power button
Press to turn on the computer if it
is turned off or in Sleep state.
Press to put the computer in Sleep
state if it is turned on.
Press and hold for 4 seconds to
force shut‑down the computer.
NOTE: You can customize the
power‑button behaviour in Power
Options. For more information,
see Me and My Dell at
dell.com/support.
2 Optical drive
Reads from and writes to
CDs and DVDs.
3 Microphone port
Connect an external microphone
to provide sound input.
4 USB 2.0 ports (2)
Connect peripherals such as
storage devices, printers, and so
on. Provides data transfer speeds
up to 480 Mbps.
5 Optical-drive eject button
Press to open or close the
optical‑drive tray.
6 Headphone port
Connect a headphone or speakers.
7 Media-card reader
Reads from and writes to
media cards.
8 Front I/O-panel door
(open)
Covers the Front I/O‑panel.
9 Hard-drive activity light
Turns on when the computer
reads from or writes to the
hard drive.
Front
8
9
7
6
5
4
1
2
3
