Page 12 For technical questions, please call 1-800-444-3353. SKU 98107
speciFicatiOns
Electrical Requirements 120 V~ / 60 Hz / 7.5 A
Motor No Load Speed
10,500 RPM
Wheel Diameter 4-1/2 inches
Arbor Diameter 7/8 inch
Spindle Thread 5/8 inch x 11 TPI
e194601
90sM
unpacKing
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please
call Harbor Freight Tools at the number
shown on the cover of this manual as soon
as possible.
list of contents
description Q’ty
Angle Grinder 1
Grinding Wheel 1
Quick Release Wheel Guard 1
Auxiliary Handle 1
Pin Wrench 1
Owner’s Manual 1
instructiOns FOr
putting intO use
read the entire iMpOrtant
saFetY inFOrMatiOn
section at the beginning of this
manual including all text under
subheadings therein before set
up or use of this product.
tO preVent
seriOus injurY
FrOM accidental
OperatiOn:
turn the power switch of the
tool to its “OFF” position and
unplug the tool from its
electrical outlet before
assembling or making any
adjustments to the tool.
note: For additional information regarding
the parts listed in the following pages,
refer to the Assembly Diagram near
the end of this manual.
assembly
installing the wheel guard
The Wheel Guard (7) must be in- 1.
stalled before installing a grinding
wheel or other disc.
Loosen the Wheel Guard Quick Re-
2.
lease (3) by pulling the lever outward.
Slide the collar of the Wheel Guard
3.
(7) over the rim of the Front Cover
(14).
Rotate the position of the Wheel
4.
Guard as needed for the planned
work.
Tighten the Wheel Guard Quick Re-
5.
lease by pressing the lever back in
place. The clamping pressure of the
Quick Release may be adjusted us-
ing the Nut (8).
Check the Wheel Guard to ensure it
6.
is firmly in place. Adjust if necessary
before proceeding.
