Cub Cadet 10M - Manual (Page 9)

9 s
ectiOn
3 — a
sseMbly
& s
et
-u
p
Side Discharge Chute
Your mower is shipped as a mulcher. To convert to side
discharge:
Lift the mulching plug. See Figure 3-5.
Slide two hooks of side discharge chute under hinge pin on
mulching plug assembly. Lower the mulching plug.
1.
2.
The rope guide is attached to the right side of the upper
handle. See Fig. 3-3. Loosen the wing nut which secures the
rope guide.
Hold blade control against upper handle.
Pull starter rope out of the engine. Release blade
control.
Slip starter rope into rope guide.
Tighten wing nut.
Insert post on cable tie into hole provided on the lower
handle. Pull cable tie tight and trim excess. See Figure 3-4.
3.
a.
b.
c.
d.
4.
A
C
D
B
Figure 3-3
Figure 3-4
Figure 3-5
2
1
