29
CONNECTING TO GAS SUPPLY
Connection to the appliance should be made with an approved appliance
flexible connection to BS 669. A length of 0.9 to 1.25m is recommended. The length of
hose chosen should be such that when the cooker is in situ, the hose does not touch
the floor. LPG models should be connected with a hose suitable for LPG and capable of
withstanding a pressure of 50mbar.
The temperature rise of areas at the rear of the cooker that are likely to come in
contact with the flexible hose do not exceed 70°C.
GAS CONNECTION
CONNECTING TO THE GAS SUPPLY
The cooker is designed to match the depth of standard 600mm work tops. An
adaptor backplate should, therefore, be fitted within the shaded area shown in to
allow the cooker to be pushed fully to the wall. If a forward facing backplate elbow is
used it must be chased into the wall.
540
537
225 237
510
190
75
540
