121
Appendix
The numbers in parentheses indicate the pages where each item is explained.
.
Camera
.
Charger Unit
General Guide
1 Shutter button (page 16)
2 [ON/OFF] (Power)
(page 22)
3 Flash (page 26)
4 Front lamp
(pages 18, 52)
5 Lens
6 Microphone
(pages 39, 68)
7 Back lamp
(pages 16, 22, 26)
8 Zoom button
(pages 16, 36, 62)
9 Strap hole (page 2)
bk Connector cover
bl USB/AV port
(pages 63, 72, 80, 89)
bm [r] (REC) button
(pages 16, 22)
bn [SET] button (page 23)
bo [BS] button (page 42)
bp [MENU] button
(page 46)
bq Control button
([8] [2] [4] [6])
(page 23)
br [p] (PLAY) button
(pages 19, 22)
bs Monitor screen
(pages 105, 122)
3 4 2 1
5
6
8 7 9 bk
bl
bm
bo bp bq br bs bn
[ ]
[ ]
[ ]
[ ]
[SET]
Front Back
bt Battery/memory card slots (pages 11, 14, 116, 118)
ck Tripod hole
Use this hole when attaching to a tripod.
cl Speaker
ck cl
bt
Bottom
3
2 1
1 [CHARGE] Lamp
2 +- Contacts
3 AC jack
