PARTS LIST
Burner
Assembly for
Radiant Models
PART NUMBER FOR
KEY
NO.
CGR65BPA CGR65PA CGR50BPA CGR50PA CGR35PA DESCRIPTION QTY.
1 100729-03 100729-03 100729-02 100729-02 100729-01 Combustion Chamber 1
2 098324-02 098324-02 098324-02 098324-02 098324-02 Control Knob 1
3 097159-01 097159-01 097159-01 097159-01 097159-01 Piezo Ignitor 1
4 098271-05 098271-05 098271-05 098271-05 098271-05 Ignitor Cable 1
5 099974-03 099974-03 099974-02 099974-02 099974-01 Control Rod 1
6 063017 063017 100481-01 100481-01 063015 Limit Switch Bracket 1
7 M11084-26 M11084-26 —— —— M11084-26 Screw, #10-16 x 3/8" 6
—— —— M11084-26 M11084-26 —— Screw, #10-16 x 3/8" 5
8 099986-02 099986-02 099986-01 099986-01 099986-01 Wire Assembly 1
9 100000-01 100000-01 100000-01 100000-01 100000-01 Cotter Pin 1
10 231939 231939 231939 231939 231940 Limit Switch 1
11 M11084-38 M11084-38 M11084-38 M11084-38 —— Screw, #8-18 x 3/8" 3
—— —— —— —— M11084-38 Screw, #8-18 x 3/8" 2
12 099211-01 099211-01 099211-01 099211-01 099211-01 Screw, #10-16 x 2 1/4" 2
13 100207-02 100207-02 100207-02 100207-02 100207-02 Control Valve 1
14 098265-01 098265-01 098265-01 098265-01 098265-01 Elbow 1
15 098936-02 098936-02 098936-02 098936-02 098936-02 Thermocouple Interrupter 1
16 100028-02 100028-02 100028-02 100028-02 100028-02 Pilot Tubing 1
17 100307-01 100307-01 100307-01 100307-01 100307-01 Thermocouple 1
18 171176 171176 171176 171176 171176 Burner Tube 1
19 530988 530988 530988 530988 530988 Control Bracket 1
20 100309-01 100309-01 100309-01 100309-01 100309-01 Orifice Holder 1
21 180252 180252 530124 530124 100469-01 Orifice 1
22 100706-01 100706-01 100385-01 100385-01 100384-01 Burner Assembly 1
23 100310-01 100310-01 100310-01 100310-01 100310-01 Pilot Mounting Bracket 1
24 100308-02 100308-02 100308-02 100308-02 100308-02 Pilot (Includes 30 & 31) 1
25 M12461-25 M12461-25 M12461-25 M12461-25 M12461-25 Screw, 10-32 x 1/4" 2
26 098249-01 098249-01 098249-01 098249-01 098249-01 Nut, M5 x 0.8 2
27 101342-03 101342-03 101342-02 101342-02 101342-01 Glass Panel Package
(Includes Retainer) 1
28 100772-01 100772-01 —— —— —— Radiant 5
—— —— 100772-01 100772-01 —— Radiant 4
—— —— —— —— 100772-01 Radiant 3
29 530192 530192 530192 530192 530192 Glass Spring 2
30 100468-01 100468-01 100468-01 100468-01 100468-01 Pilot Electrode 1
31 100465-01 100465-01 100465-01 100465-01 100465-01 Electrode Nut 1
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Ordering Replacement Parts on page 36 of this manual.
