NOTE: You do not need to disassemble any additional parts to mount
the heater.
6. Connect the grounding lead to the grounding screw (See Figure 4).
Both sides of the heater include a grounding screw.
Installation Instructions
WIRING
COMPARTMENT COVER
MOUNT
SECURELY
TO WALL
Figure 7
Model
8F2025
Only
SUPPLY
WIRES
B
A
GROUND
DO ISCONNECT
Figure 6
B
A
DO ISCONNECT
GROUND
STEP 2: Baseboard Wiring
1. Verify the electrical supply wires are the same voltage as the
heater. Check heater specifications to ensure correct wiring.
Failure to do so may destroy the heater and void your warranty.
Both 120 volt and 240 volt baseboard wiring utilize 3 supply wires.
120 volt baseboard wiring: 1 hot, 1 neutral and 1 ground.
240 volt baseboard wiring: 2 hot and 1 ground. No neutral needed.
For all baseboard wiring applications, both supply wires must be
connected to at least one (1) heater wire.
2. Disconnect one factory connector (See Figure 6. Model 8F2025 See
Figure 7). If wiring on the left side, disconnect factory connector
A. If wiring on the right side, disconnect factory connector B.
NOTE: There are no loose wires provided with the baseboard.
This is due to the ability to wire the baseboard on either the right
or left side of the heater.
3. Proceed to the next step.
STEP 1: Mount Heater to Wall
1. Locate wall studs closest to supply wires and position heater
(See Figure 1). NOTE: Wire connection is possible from either right
or left side of the baseboard heater.
4. Pull supply wires through the connector and secure leaving 6 inch
wire leads for later use (See Figure 4).
5. Mount the heater securely to the wall with nails or screws going into at
least two wall studs (See Figure 5). The back of the heater has “star punch”
dimples that allow nails or screws to easily pierce the sheet metal.
STUDS
SUPPLY
STUDS
FLOOR
FINISHED
WALL
2. Remove the wiring compartment cover by removing the screw
(See Figure 2). The wiring compartment is an approved junction
box for the baseboard only. No additional junction box is required.
3. Remove the slotted knockout closest to the sup ply wires and install
a strain relief connector (See Figure 3).
JUNCTION BOX
GROUND SCREW
WIRING
COMPARTMENT
COVER
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
DO NOT DISCONNECT
GROUND
DO NOT DISCONNECT
GROUND
