QuickSpecs
Compaq Flat Panel Monitor Rackmount (TFT450R)
DA-10249 Canada — Version 6 — March 19, 2001 2
O V E R V I E W (continued)
Kit Contents
The Compaq Flat Panel Monitor Rackmount (TFT450R) comes standard with the following:
• Compaq TFT450 Flat Panel Monitor with plastic frame, retractable tray, and slide rails attached
• Rail Mounting Brackets (2)
• Cable management arm with hardware
• Latch Bracket
• Fixed Mounting Bracket
• Fixed Monitor Faceplate
• Rack template cards (2)
• M6 screws (8)
• AC Adapter
• AC Power Cord
• Cable Management Arm Fasteners
• Stabilizing Bracket with thumbscrews(2)
• 8-32 x 1/4 screws (4)
• Compaq Flat Panel Monitor Rackmount (TFT450R) User Guide
Warranty
Three-year parts, first year on-site labour, Backlights-one year, on-site. Certain restrictions and exclusions apply. Consult the Compaq Customer Support
Center for details. In Canada, consult the Product Information Centre at 1-888-88-COMPAQ.
S P E C I F I C A T I O N S
Overall Picture Tube (diagonal)
Viewable (diagonal)
Horizontal Dot Pitch
Pixel Clock Speed
Input Impedance
Horizontal Frequency
Maximum Power Rating
Power Supply ALS
14.5 in/37 cm Flat Panel
14.5 in/37 cm
0.28 mm
78.75 MHz
75 ohms
± 10%
31.5 to 60.2 KH z
< 35W
Universal/Auto-Sensing
90 to132/195 to265 VAC
47 to 63 Hz
Graphic Preset Modes 1024 x 768
800 x 600
40 x 480
640 x 350 60, 70 and 75 Hz
60, 70 and 75 Hz
60, 70 and 75 Hz
70 Hz
Language Selection English
Spanish
French
German
Dutch
Physical Dimensions Dimensions (HxWxD) 3.4 x 17.8 x 30.5 in (retractable mode)
8.6 x 45.2 x 77.5 cm (retractable mode)
Weight 25 lbs/11.3 kg with rack mounting
13.4 lbs/6.1 kg fix mounted
