TECHNICAL DATA
DIMENSIONS
Height 900 - 915mm
Width 600mm
Depth 595mm (excluding door handles)
GENERAL
Gas connection Rp 1 /
2
( 1 /
2
” BSP female)
Pressure test point Hotplate burner injector.
Gas rate adjustment None
Aeration adjustment None
Electrical connection 4mm 2 twin and earth.
230-240V a.c. 50Hz.
25
INSTALLATION INSTRUCTIONS
HOTPLATE
Front left and rear right
HOTPLATE
Front right and rear left
3.0kW 128
Heat Input Injector
Natural Gas LPG
1.9kW 102
2.8kW
(205g/h)
82
Heat Input Injector
1.8kW
(130g/h)
65
GRILL 2.4 / 2.6kW
TOP OVEN 1.7 / 1.85kW
MAIN OVEN 2.3 / 2.5kW
