30

APPENDIX B SSP-60 Mode Chart


Below are the available modes (subject to change) and the active speakers in each case.

The subwoofer is not included in the table since it is active if selected in the speaker setup
and if any of the active speakers are set as “small”.

MODE

Signal Type

Processing

Output from Speakers

Mono

Dolby Digital EX

Mono downmix

C

Dolby Digital 5.1

Mono downmix

C

Dolby Digital 2/0

Mono downmix

C

DTS-ES Discrete

Mono downmix

C

DTS-ES Matrix

Mono downmix

C

DTS 3/2

Mono downmix

C

PCM

Mono downmix

C

Analog

Mono downmix

C

Stereo

Dolby Digital EX

Stereo downmix

L, R

Dolby Digital 5.1

Stereo downmix

L, R

Dolby Digital 2/0

Not applicable

Not applicable

DTS-ES Discrete

Stereo downmix

L, R

DTS-ES Matrix

Stereo downmix

L, R

DTS 3/2

Stereo downmix

L, R

PCM

No processing

L, R

Analog

No processing

L, R

Stereo 96

Dolby Digital EX

Not applicable

Not applicable

Dolby Digital 5.1

Not applicable

Not applicable

Dolby Digital 2/0

Not applicable

Not applicable

DTS-ES Discrete

Not applicable

Not applicable

DTS-ES Matrix

Not applicable

Not applicable

DTS 3/2

Not applicable

Not applicable

PCM

Not applicable

Not applicable

Analog

A/D 24/96

L, R

Direct

Dolby Digital EX

No processing

L, R, C, LS, RS

Dolby Digital 5.1

No processing

L, R, C, LS, RS

Dolby Digital 2/0

No processing

L, R

DTS-ES Discrete

No processing

L, R, C, LS, RS, LB+RB

DTS-ES Matrix

No processing

L, R, C, LS, RS

DTS 3/2

No processing

L, R, C, LS, RS

PCM

Not applicable

Not applicable

Analog

Not applicable

Not applicable

Dolby Pro Logic /

Dolby Digital EX

Not applicable

Not applicable

Pro Logic II Movie &

Dolby Digital 5.1

Not applicable

Not applicable

Pro Logic II Music

Dolby Digital 2/0

Dolby PL / PLII

L, R, C, LS, RS

DTS-ES Discrete

Not applicable

Not applicable

DTS-ES Matrix

Not applicable

Not applicable

DTS 3/2

Not applicable

Not applicable

PCM

Dolby PL / PLII

L, R, C, LS, RS

Analog

Dolby PL / PLII

L, R, C, LS, RS

Note: LB+RB indicates that a single rear (back) surround signal is played by both rear channels.

Continued on following page
