1 6

1/4” x 13 mm Screw (x6)

Ø7 Flat Washer (x6)

No.10 x 10 Screw (x6)

Ø5 Flat Washer (x6)

Ø5 Lock Washer (x6)

Ø7 Lock Washer (x6)

Hardware Pack List

No.

Description

Part Number

Quantity

1

1/4”-20UNC x 13 Screw

20120-13013-250

6

2

Ø7 Washer

40300-07000-250

6

3 Ø7

Lock

Washer

41400-07000-250

6

4

No.10-24UNC x 10 Screw

20124-10010-250

6

5 Ø5

Washer

40300-05000-250

6

6 Ø5

Lock

Washer

41400-05000-250

6

7 AA

BATTERY

G401-0088-9000

1

A S S E M B L Y I N S T R U C T I O N S

Before assembling the barbecue, read these instructions carefully.

Assemble the barbecue on a flat, clean surface. Grill is heavy. You

should have two people assemble the barbecue together.

Notes: Do not fully tighten all the nuts during this initial stage.

Caution: Sheet metal can cause injury. Wear gloves when installing

the grill. Use care when assembling.

#2 Phillips

®

screwdriver

1/4˝ slotted screwdriver

Adjustable wrench

Pliers

Rubber mallet

Tools Needed for Assembly
