Page 10
11-10
Cisco 1800 Series Routers (Modular) Hardware Installation Guide
OL-5876-03
Chapter 11 Installing and Upgrading Internal Modules in Cisco 1800 Series Routers (Modular)
Modules Internal to the Cisco 1841 Router
Figure 11-9
Connecting the AIM to the System Board
Step 6
Check that the AIM is installed correctly on the system board. See
.
121108
Metal standoffs
Snap-in
plastic
standoff
AIM
