13
Specifications
Acoustic Speaker Compliment
Woofer 10” Diameter, 40 Oz. Magnet, 2” Dia. Voice Coil, 6 Ohm
Tweeter Compression Horn Driver, 12 Oz. Magnet, 1” Voice Coil, 8 Ohm
Frequency Response 45Hz to 18KHz
Amplifier 90 Watts RMS @ 5% THD (AC)
Sound Pressure Level 94 dB, 1 Watt @ 1 Meter
Power Sources 100-240 volt AC switchmode power supply and 12 volt 7 AH
maintenance-free lead acid batteries (2)
Wireless System
Receiver: Two 16-channel selectable UHF diversity wireless receivers 798-805 MHz.
Antennas are hidden internally.
Microphone Transmitters
Handheld wireless microphone or beltpack transmitters optional. Powered by 2 ea. 1.5 volt AA batteries (included). Beltpack trans-
mitter used with choice of hands-free headset, collar or lapel microphones.
CD Player
Built-in anti-shock mechanism. Fully programmable. Shuffle feature. Plays CD, CD-R/RW.
Tape Cassette
Full logic player and recorder. Automatic program search feature. 4-digit LCD tape counter. Variable speed. Auto reverse.
Transmitter to Powered Companion Speaker
16-Channel selectable UHF transmitter for wireless transmission from PA916 to multiple PA916-SP speakers. 300 ft. range.
Audio Line
Line level XLR jacks (2) providing for attaching PA916-SP speakers via cable. Features volume control for remote speaker(s).
Mixer Panel
Mixer panel accepts two wired microphones via high quality combination connectors for both XLR and 1/4” phone plugs. Voice
music switch adds emphasis in the voice range for longer range projection. Line-In via dual RCA jacks with volume control.
Line-Out via dual RCA jacks. Separate Bass and Treble tone controls. Voice priority switch activates “ducking circuit” which over-
rides music programs when microphone is used. Speaker mute switch mutes the main speaker plus all other speakers connected.
Speaker out. Both switched and unswitched 1/4” phone jacks for connecting speakers.
Dimensions 26 H x 12” W x 10” D
Weight 52 lbs.
Compliance FCC, CE, C-UL
