SKU 66891 For technical questions, please call 1-800-444-3353. Page 15
part description Qty.
1 Drive Belt Cover 1
2 Drive Belt 1
3 Screw 2
4 Holder Plate 1
5 Drive Pulley 1
6 Retaining Ring 1
7 Small Roller Bearing 1
8 Gasket 1
9 Drive Pulley Puller Pin 1
10 Roller Bearing 2
11 Holder Plate 1
12 Spindle 1
13 Screw 7
14 Spring Washer 14
15 Gear Box Cover 1
16 Bearing 1
17 Bearing Box Cap 1
18 Screw 5
19 Gear 1
20 Flat Washer 7
21 Retaining Ring 1
22 Spline 1
23 Tracking Knob 1
24 Spring 1
25 Tracking Knob Collar 1
26 Screw 5
27 Spring Washer 5
28 Flat Washer 5
29 Trigger 1
30 trigger Locating Ring 1
31 Center Bracket 1
32 Driver Wheel Rubber Ring 1
33 Driver Wheel 1
34 Camshaft 1
35 Belt Release Lever 1
part description Qty.
36 Base Plate 1
37 Belt Release Lever Holder 1
38 Sanding Belt (2-1/2” X 14”) 1
39 Spring Cap 1
40 Small Spring 1
41 Plastic Cap 1
42 Spring Locating Plate 1
43 Big Spring 1
44 Driver Wheel Bracket 1
45 Retaining Ring 1
46 Follower Wheel Pin 1
47 Follower Wheel Brush 1
48 Follower Wheel 1
49 Body Housing 1
50 Self-Tapping Screw 5
51 Rubber Ring 1
52 Bearing 1
53 Self-Tapping Screw 2
54 Orifice Plate 1
55 Rotor 1
56 Self-Tapping Screw 2
57 Stator 1
58 Motor Housing 1
59 Brush Holder (Plastic) 1
60 Brush Holder 2
61 Brush 2
62 Helicoid Spring 2
63 Bearing 1
64 Rubber Ring 1
65 Self Taping Screw 1
66 Power Cord (2-Prong Plug) 1
67 Hose Adaptor/Vent Tube 1
68 Switch 1
69 Switch Dust Shield 1
partS liSt
pleaSe read tHe Following CareFullY
tHE MANUFACtURER AND/OR DIStRIBUtOR HAS PROvIDED tHE PARtS LISt AND
ASSEMBLy DIAgRAM IN tHIS MANUAL AS A REFERENCE tOOL ONLy. NEItHER tHE
MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY
OF ANy kIND tO tHE BUyER tHAt HE OR SHE IS qUALIFIED tO MAkE ANy REPAIRS
tO tHE PRODUCt, OR tHAt HE OR SHE IS qUALIFIED tO REPLACE ANy PARtS OF
tHE PRODUCt. IN FACt, tHE MANUFACtURER AND/OR DIStRIBUtOR EXPRESSLy
StAtES tHAt ALL REPAIRS AND PARtS REPLACEMENtS SHOULD BE UNDERtAkEN
By CERtIFIED AND LICENSED tECHNICIANS, AND NOt By tHE BUyER. tHE BUyER
ASSUMES ALL RISk AND LIABILIty ARISINg OUt OF HIS OR HER REPAIRS tO tHE
ORIgINAL PRODUCt OR REPLACEMENt PARtS tHEREtO, OR ARISINg OUt OF HIS OR
HER INStALLAtION OF REPLACEMENt PARtS tHEREtO.
