S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
107
C o o p e r L i g h t i n g
P H O T O M E T R I C S
[ C o m p l e t e I E S f i l e s a v a i l a b l e a t w w w. c o o p e r l i g h t i n g . c o m ]
U C S C O N C O U R S E I I I
A R E A
A C C E S S O R I E S + M O U N T I N G S Y S T E M S
U C S 4 0 S 2 D . I E S
400-Watt HPS
50,000-Lumen Lamp
Type II
F O O T C A N D L E TA B L E
Select mounting height and read across
for footcandle values of each isofootcandle
line. Distance in units of mounting height.
Mounting
Footcandle Values for
Height
Isofootcandle Lines
A
B
C
D
E
UCS40S2D.IES
25'
2.88
1.44
0.77
0.38
0.17
30'
2.00
1.00
0.50
0.25 0.10
35'
1.50
0.75
0.37
0.18
0.07
UCS40S3D.IES
25'
2.88
1.44
0.77
0.38
0.17
30'
2.00
1.00
0.50
0.25 0.10
35'
1.50
0.75
0.37
0.18
0.07
UCS40MSL.IES
25'
2.88
1.44
0.77
0.38
0.17
30'
2.00
1.00
0.50
0.25 0.10
35'
1.50
0.75
0.37
0.18
0.07
3
2
1
3
4
0
1
2
4
1
2
3
4
3
2
1
0
A
B
C
D
E
3
2
1
3
4
0
1
2
4
1
2
3
4
3
2
1
0
A
B
C
D
E
4
3
2
1
0
1
2
3
4
0
1
3
2
4
3
1
2
4
A
E
D
B C
U C S 4 0 S 3 D . I E S
400-Watt HPS
50,000-Lumen Lamp
Type III
U C S 4 0 M S L . I E S
400-Watt MH
40,000-Lumen Lamp
SLE-Spill Light Eliminator
Direct Arm Mountings
Pole Top Mountings *
Square Pole
Round Pole
Square Pole
Round Pole
CA40BZ (E.P.A. .2)
CA41BZ-3"Dia. Pole (E.P.A. .2)
CA43SBZ
CA43RBZ
CA42BZ-3 1/2"-4" Dia. Pole (E.P.A. .2)
CA44SBZ
CA44RBZ
CA45SBZ
CA45RBZ
CA46SBZ
CA46RBZ
Wall Mount Adapter
* For 2 3/8"-3" O.D.
CA47RBZ
CA-14BZ
6 1/4"
[159mm]
6 3/8"
[162mm]
6 1/4"
[159mm]
6 3/4"
[171mm]
8 1/2"
[203mm]
M O U N T I N G C O N F I G U R AT I O N S
Wall Mount
Arm Mount Single
Arm Mount 2 @ 180°
Arm Mount 2 @ 90°
Arm Mount 3 @ 120°
(Round Pole Only)
Arm Mount 4 @ 90°
Arm Mount 3 @ 90°
D R I L L I N G PAT T E R N
T Y P E “ E ”
T O P M O U N T I N G F O R S Q U A R E A N D R O U N D P O L E S
[ o r d e r s e p a r a t e l y ]
Accommodates 2 3/8"—3" O.D. vertical tenons (arm included). Catalog number includes slipfitter and mounting arm(s). Square unit height is 6 1/4". Round unit
height is 6 3/4".
7/8'' [23 mm]
2 11/16''
[69 mm] 3/4'' [20 mm]
dia. hole
(2) 3/8" [10 mm]
dia. holes
3 7/8''
[99 mm]
CA43S
CA44S
CA45S
CA46S
CA43R
CA44R
CA45R
CA46R
CA47R
C ATA L O G N U M B E R
E . P. A .
W T. ( l b s . )
CA43S
1.2
39
CA44S
2.3
75
CA45S
2.3
75
CA46S
2.3
146
CA43R
1.2
39
CA44R
2.3
75
CA45R
2.3
75
CA46R
2.3
145
CA47R
2.4
111
E.P.A. TABLE
SINGLE
DRILL PATTERN
[W/Arm where applicable]
2 @ 180°
2 @ 90°
3 @ 90°
3 @ 120°
4 @ 90°
UCS
“E”
1.1
2.2
2.2
3.1
3.1
3.55
