Steering & Travel
STEERING
You control steering by moving the control handle from side to side.
For example: This picture shows the directions the truck can turn when
the control handle is moved to the approximate position shown.
Travel, power
unit first Travel,
forks first
Dire
cti
on
of
Tu
rn
Steering & Travel 18
D
ir
ec
tio
n
of
Tu
rn
Know the Hazards
POWER UNIT SWING
Be careful turning while traveling forks first. The power
unit will swing wide in the opposite direction. Make sure
you have clearance, and watch out for people in the area.
SLOW DOWN FOR SPILLS OR WET FLOORS
Powder or liquid spills can cause slippery floors. Slow
down or you could lose control of steering and braking.
Be careful and allow for a longer stopping distance.
Don't run over objects on the floor.
Raising & Lowering
17 Raising & Lowering
RAISE/LOWER
Move the Raise/Lower lever away from the mast,
toward the control arm, to raise the forks. Move the
lever toward the mast to lower the forks.
The farther you move the lever from neutral, the faster
the forks will move.
RAISE & LOWER PUSH BUTTONS
For convenience, single speed push buttons may be installed
on the control handle. Push either the Raise or Lower
button until the forks are at the desired height.
