Dc power connector p4, Dc power connector p6, Dc power connector p7 – Dell Dimension 8400 User Manual

Page 45: Dc power connectors, p8 and p9

background image



DC Power Connector P4



DC Power Connector P6



DC Power Connector P7



DC Power Connectors, P8 and P9

2

COM

Black

3

+5 VDC

Red

4

COM

Black

5

+12 VB DC

White



Pin Number



Signal Name



18-AWG Wire

1

N/C

N/C

2

COM

Black

3

COM

Black

4

+3.3 VDC

Orange

5

+5 VDC

Red

6

+12B VDC

White



Pin Number



Signal Name



18-AWG Wire

1

+12 VB DC

Yellow

2

COM

Black

3

COM

Black

4

+5V DC

Red



Pin Number



Signal Name



18-AWG Wire

1

+5 VDC

Red

2

COM

Black

3

COM

Black

4

+12 A VDC

Yellow



Pin Number



Signal Name



18-AWG Wire
