Cabletron Systems TRXI-42A - Manual (Page 23)

REQUIREMENTS/SPECIFICATIONS
Page 2-11
2.3 COM 1/COM 2 PORT SPECIFICATIONS
The RJ45 COM 1 and COM 2 ports support Console, Modem, UPS,
and SLIP applications. A description of each COM port application is
listed below:
Note: Console is the only COM port application available at this time.
Modem, UPS, and SLIP applications will be available in future TRXI
releases.
Figure 2-2. COM 1/COM 2 Ports
Console
The COM 1 port, as default, supports access to a Local Management
Console. The console supports a Digital Equipment Corporation VT
320™ terminal or PC emulation of the VT 320 terminal.
Modem
Both the COM 1 and COM 2 ports support access to Local
Management using a modem.
UPS
The COM 2 port supports an Uninterruptible Power Supply
(American Power Conversion only).
SLIP
The COM 1 and COM 2 ports support the Serial Line Internet
Protocol.
TRXI-24A TOKEN RING HUB WITH LANVIEW®
COM 2 COM 1
DISPLAY RESET
