CERWIN-VEGA! PROFESSIONAL ACTIVE SERIES
SPECIFICATIONS
Full Range Active Speaker
System Type
Dual 8 inch active full range speaker
Power Capacity
Continuous 400 watts
Peak 800 watts
Frequency Response (±3 dB) 70 Hz - 20 kHz
Frequency Range (-10 dB) 60 Hz - 20 kHz
Max SPL 128 dB at 800 watts
Sensitivity (1w/1m) 99 dB
HF Driver CD34B
voice coil 34mm
MLF Driver FR8C, 8 inch
voice coil 2 inch
LF Driver FR8B, 8 inch
voice coil 2 inch
Construction Multi-ply Hardwood
Finish Cool-X® Polyurethane Paint or Carpet
Dimensions (H x W x D) 20.5 inch x (front)11 inch (rear)8.5 inch
x 12 inch
520 mm x (front)279 mm (rear) 216 mm
x 305 mm
Net Weight 48 lb (21.8 kg)
Amplifi er Module
Power Rating 400 watts / 800 watts peak
Input Connectors XLR/F Balanced
1/4 inch TRS
Output Connectors XLR/M
1/4 inch TRS
Controls Level
Line/Mic-D.I.
No Sub/With Sub
Contour/Off
Power
Voltage Selector
Nominal Beamwidth Horizontal 50˚
(-6 dB SPL Points) Vertical 50˚
3
Power Source
Warning:
Do not daisy chain more
than three CVA-28 units
from the power source!
8.5” (216 mm)
11” (279 mm)
8.5” (216 mm)
12” (305 mm)
12” (305 mm) 11” (279 mm)
20.5” (520 mm)
