Vista traseira (orientação de computador de mesa)
Conectores do painel traseiro
3
2
4
1
1
slots de placas
Acesse os conectores de qualquer placa PCI ou PCI Express instalada.
2
conector de energia
Insira o cabo de alimentação neste conector.
3
chave seletora de tensão
Consulte as instruções de segurança contidas no
Guia de Informações do Produto
para obter mais informações.
4
conectores do painel
traseiro
Conecte dispositivos seriais, USB e outros aos conectores adequados.
1
2
3
4
5
9
10
11
12
6
7
8
