Carrier TB-NHP - Manual

TB---NAC
TB---NHP
Base Series
Non---Programmable Thermostat
Installation Instructions
Designed and Assembled
in the USA.
US patents: US20060165149 A1, USD578026 SI, US6205041 B1
A07108
Base Non---Programmable Thermostat
NOTE: Read the entire instruction manual before starting the
installation.
TABLE OF CONTENTS
PAGE
SAFETY CONSIDERATIONS 1 . . . . . . . . . . . . . . . . . . . . . . . . .
INTRODUCTION 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTALLATION CONSIDERATIONS 1 . . . . . . . . . . . . . . . . . . .
INSTALLATION 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 1 — Thermostat Location 2 . . . . . . . . . . . . . . . . . . . . . . . .
Step 2— Install Thermostat 2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 3 — Set Thermostat Configuration 2 . . . . . . . . . . . . . . . . .
Step 4 — Thermostat Operation 3 . . . . . . . . . . . . . . . . . . . . . . . .
Step 5 — Check Thermostat Operation 3 . . . . . . . . . . . . . . . . . .
WIRING DIAGRAMS 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SAFETY CONSIDERATIONS
Improper installation, adjustment, alteration, service, maintenance,
or use can cause explosion, fire, electrical shock, or other
conditions which may cause death, personal injury, or property
damage. Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The qualified
installer or agency muse use factory--authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Follow all safety codes. Wear safety glasses, protective clothing,
and work gloves. Have a fire extinguisher available. Read these
instructions thoroughly and follow all warnings or cautions
included in literature and attached to the unit. Consult local
building codes and the current editions of the National Electrical
Code (NEC) NFPA 70.
In Canada, refer to the current editions of the Canadian Electrical
Code CSA C22.1.
Recognize safety information. This is the safety--alert symbol .
When you see this symbol on the unit and in the instructions or
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and
CAUTION. These words are used with the safety--alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies a hazard
which could result in personal injury or death. CAUTION is used
to identify unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or
operation.
INTRODUCTION
The Base Series thermostat is an electronic 24VAC,
non--programmable, manual changeover wall mount thermostat.
This thermostat uses a single setpoint to maintain and control room
temperature in both the heating and air conditioning modes. The
thermostat is designed to maintain +/-- 2_F accuracy. No batteries
are required; temperature, fan, mode, and installer configuration
settings are preserved with power off.
INSTALLATION CONSIDERATIONS
Air Conditioner Model
TB--NAC, Base Series Model air conditioner thermostat, may be
wired with or without connecting a common wire between the
indoor equipment and the thermostat. However, it is recommended
to use a common wire whenever possible. Without a common wire
this thermostat becomes “power stealing.” This means it will need
to steal a small amount of power from the equipment to which it is
connected.
NOTE: Not all HVAC equipment is compatible with power
stealing type thermostats. All Carrier equipment is directly
compatible with this thermostat except the Thermostat Conversion
Kit, Part #TSTATXXCNV10. For all non--Carrier equipment,
consult the system equipment Installation Instructions before
applying this thermostat in a power stealing manner.
Heat Pump Model
TB--NHP, Base Series Model heat pump thermostat, is compatible
with all Carrier heat pump systems. It is NOT power stealing and
