FRIGIDAIRE FHWC3060LS - Manual

Signature Features
Glass Canopy Design
Glass and stainless steel construction
is as attractive as it is functional.
Centrifugal Fan
Move air quietly and efficiently — up
to 400 cu. ft. of air per minute.
Halogen Lighting
For bright illumination of the cooktop
surface.
Washable Filters
Dishwasher-safe for easy cleaning.
The aluminum filter provides strength
and durability not found in foam
filters.
frigidaire.com
Glass Canopy Wall-Mount Hood
FHWC3060L S
30" Stainless Steel
Stainless
(S)
* Ventilation is convertible to be either ducted outside,
or recirculated inside requiring no ducting. (Recirculated
option requires use of optional Duct-Free Kit.)
‡ For use on adequately wired 120V, dedicated circuit having
2-wire service with a separate ground wire. Appliance must be
grounded for safe operation.
NOTE: Always consult local and national electric codes. Check
local building codes for installation requirements, as they may
vary per locale. Refer to Product Installation Guide for detailed
installation instructions on the web at frigidaire.com.
Specifications subject to change.
Available in:
Features
Nominal Width 30"
Installation Type Wall Mount
Style
Stainless Steel /
Glass Canopy
Air Discharge Vertical
Air Delivery (CFM) 400
Blower Type Centrifugal
Controls
Electronic
Push Button
Fan Speeds 3
Sound Level (dBA) 67.1
Dual Halogen Lights Yes
Dishwasher-Safe Filter Yes
Exhaust Duct Convertible*
Duct Required 6" Round
Optional Accessories
Duct-Free Kit PN # FHWRKT60LS
10' Flue Extension Kit PN # FHW10X60LS
Specifications
Product Dimensions –
Height (With One Cover)
(With Flue Extension) 22-11/16" min.
26-1/2" min.
43-29/32" max
Width 29-7/8"
Depth 19-11/16"
Voltage Rating 120V / 60Hz / 15A
Amps @ 120 Volts 4.0
Connected Load (kW Rating)
@ 120 Volts ‡
0.516
Shipping Weight (Approx.) 50 Lbs.
Sones Rating 6.5
