Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
1 Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC
only electrical supply with ground required on separate circuit fused on
both sides of line.
2 Cooktops are approved for installation above any of our Electric Single
Wall Ovens.
Granite Countertop
Installation Kit available.
Product Dimensions
A - Width
B - Depth
C - Height 36-3/4"
21-3/8"
2-5/8"
Cutout Dimensions
Width (Min.) / (Max.)
Depth (Min.) / (Max.)
Height 35-5/8" / 36-1/8"
20-1/4" / 20-1/2"
5"
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web
at frigidaire.com.
Drop-In Electric Cooktops
Frigidaire Baseline
A
B
C
Features
Controls
Surface Type
Right Front Element (Watts)
Right Rear Element (Watts)
Left Front Element (Watts)
Left Rear Element (Watts)
Center Element (Watts)
Hot Surface Indicators
Control Location
Knob Color
Knob Type
Specifications
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts 1
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Approved for Electric Single
Wall Oven Combination Installation 2
Shipping Weight (Approx.)
Express-Select®
Black Ceramic Glass (S)
Color-C. Ceramic Gl. (W/B)
6" / 9" - 1,600 / 3,000
7" - 1,500
12" - 2,700
6" - 1,200
7" - 1,500
Yes
Right Side
Black (S)
Color-Coordinated (W/B)
Plastic
Right Rear
240V /208V / 60Hz
9.6 / 7.2
40.0 / 34.6
40
Yes
65 Lbs.
USA • 10200 David Taylor Drive • Charlotte, NC 28262 • 1-800-FRIGIDAIRE • frigidaire.com
CANADA • 5855 Terry Fox Way • Mississauga, ON L5V 3E4 • 1-800-265-8352 • frigidaire.ca
FGEC3645K 03/11 © 2011 Electrolux Home Products, Inc.
Built-In Cooktops
FGEC3645K S/W/B 36" Electric
