Specifications
subject to change.
NOTE: For planning purposes only. Always consult local and national electric and plumbing codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
B
A
D
C
24" Built-In Dishwashers
Frigidaire Baseline
Meets requirements
of ASSE 1006
Accessories information available
on the web at frigidaire.com
USA • 10200 David Taylor Drive • Charlotte, NC 28262 • 1-800-FRIGIDAIRE • frigidaire.com
CANADA • 5855 Terry Fox Way • Mississauga, ON L5V 3E4 • 1-800-265-8352 • frigidaire.ca
FDB2410HI 03/14 © 2014 Electrolux Home Products, Inc.
Features
Control Design
Digital Display
Door Latch
Stay-Put Door Hinge Design
Low Rinse-Aid Indicator Light
Interior Design
Interior Color
Wash System
Wash Levels / Wash Speeds
Sound Package
Filter
Filter Trap
Soft Food Disposer
dB Level
Drying System
Cycles
Number of Cycles
Heavy
Normal
Light
Delicate
Favorite
China / Crystal
Rinse Only
Energy Saver Plus
Upper Rack Wash Only
Cycle Indicator Light
Control Lock
Options
Heat / No Heat Dry
Hi-Temp Wash
NSF® Certified Sanitize Rinse
Delay Start
Rack System
Rack Design / Rack Coating
Upper Rack –
Stemware / Champagne Glass Holders
Fold-Down Tines
Cup Shelves
Lower Rack –
SpaceWise® Silverware Basket
Fold-Down Tines
Small Items Cover
Certifications
ENERGY STAR®
A.D.A. Compliant1
Specifications
Water Inlet Location
Water Usage (Gallons)
Water Pressure (PSI)
Integral Air Gap on Supply
Leveling Legs
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @ 120 Volts
2
Amps @ 120 Volts
Shipping Weight (Approx.)
Ready-Select®
Yes
Yes
Yes
Yes
Tall Tub
Stainless Steel
Direct
5 / 1
UltraQuiet™ 3
Stainless Steel
Removable
Yes
56
Static
5
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1–24 Hour
Deluxe / Nylon TufRacks™
Yes
Yes
2
3-Piece Split
3
Yes
Yes
Left Bottom Front
5.4
20 – 120
Yes
4
Right Bottom Front
120V / 60 Hz / 15A
1.44
10
69 Lbs.
Dishwashers
FDB2410HI C / S/ B 24" Built-In
Product Dimensions
A - Height (Adjustable)
B - Width
C - Depth (Including Door)
D - Depth (To Tub Flange)
Depth with Door Open 90° 32-1/2" – 34-7/8"
24"
23"
20-1/2"
46"
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Max.)
Depth (Min.) 32-1/2" (A.D.A. 1 )
35"
24"
24"
1 When properly installed, this model is A.D.A.-qualified based on the
United States Access Board’s A.D.A./A.B.A. Accessibility Guidelines and
the Department of Justice’s 2010 A.D.A. Standards for Accessible Design.
1 For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe operation.
