TRANSMITTER PROGRAMMING

Note: All transmitter codes must be learned at time of programming!! The unit will learns up to 4
different transmitter codes.

1. Open Hood (If no hood pin installed with your system, then you must ground the Blue Hood pin wire).
2. Turn key to the ON position.
3. Press Programming button 4 times, then after a few seconds the unit flashes the parking lights 4 times.
4. Press button #1 on the transmitter to be coded. You should get 2 light flashes indicating the unit is waiting

for a 2

code, then press button #1 on the second transmitter, the unit will flash 3 times indicating its

waiting for the 3

code and so on. If all 4 codes are learned, the unit will automatically exit code learning

mode, otherwise turn key off and close hood. See diagram below.

IGN

OFF

WAIT FOR

4 FLASHES

PRESS 4X's

FLASH 2, 3, or 4 X's

(BLUE WIRE GROUNDED)

IGN

OFF

START
