7
DOOR REMOVAL INSTRUCTIONS
To prepare for removing the
doors:
1 Make sure the electrical power cord is
unplugged from the wall outlet.
2 Open both doors and remove the toe
Socket
Wrench Set
Adjustable
Wrench
3/8" Fixed
Wrench
Top Hinge
Cover Front
Screw
Top
Hinge
Screw
Bottom
Hinge
Screw
Top Hinge
Cover Rear
Screw
Phillips™
Head
Tools Necessary:
or
or
To remove the refrigerator door:
1 Trace lightly around the door’s top hinge
with a pencil. This makes reinstallation
easier.
grille (as explained in the Installation
Instructions that came with your
appliance).
3 Remove any food from the door shelves.
4 Close the doors.
To remove the refrigerator top
hinge cover:
1 Remove the three screws from each cover
over the top door hinges.
2 Lift hinge cover straight up and off.
Rear Cover
Screw
Front Cover
Screws
Top
Hinge
Cover
Hinge
Screws
Top
Hinge
2 Remove the two screws from the top
hinge. Lift the door off of the bottom
hinge and set it aside.
