CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426 Page -35-
CLARKE TECHNOLOGY
Encore S2426/L2426
Solution Tank Assembly Parts List 5/01
Ref. # Part No. Description Qty
1 872010 Clamp, Hose 1
2 50964A Hose, Drain 1
3 30060A Tank, Solution 1
4 59614A Valve, Battery Drain 1
5 722030 Clamp, Hose 6
6 30453A Hose, Clear Vinyl 1
7 820207 Adapter, Hose 3/8 MPT x ½ Hosebarb 1
8 30412A Hose, Stretch 2
9 51205A Adapter, Female 1
10 838517 Filter, Screen 1
11 830214 Adapter, Male, ¾ Barb x GHT Male Thread 1
12 51204A Valve, Solution 1
13 59789A Valve, Solution 1
14 38014A Splitter 1
15 81109A Nut, 8-32 ESNA SS 2
16 50966A Latch 1
17 80105A Screw, 8-32 x 1¼ SS 2
18 50963A Screen, Fill (with hose retention) 1
51308A Strainer (without hose retention) 1
19 69879A Bracket, Latch 1
20 170892 Washer, Lock ¼ 2
21 170915 Screw, ¼-20 x ¾ SS Hex 2
22 51059A Valve Assembly, Solution Shut-Off (incl. #9,12) 1
23 60480A Bracket, Hose 1
24 51346A Spring, Hose 1
25 80108A Screw, 10-24 x ½ 2
NI 30162A Funnel (included w/Kit 10177A) 1
NI 10177A Kit, Solution Fill 1
(includes #18-51308A)(includes NI - 30162A)
