CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426
Page -31-
CLARKE TECHNOLOGY
Encore S2426/L2426
Final Assembly Parts List 11/23/00
Qty
Qty
Ref. #
Part No.
Description
“L”
“S”
1
10062A
Assembly, Recovery Tank
1
1
2
10065A
Assembly, Control Panel “L”
1
-
10066A
Assembly, Control Panel “S”
-
1
3
30064A
Rear Cover
1
1
4
80108A
Screw, 10-24 x ½ SS
4
4
5
70080A
Plate, Warning
1
1
6
83010A
Rivet, Pop
1
/
8
2
2
7
10064A
Assembly, Rear Panel “L”
1
-
10067A
Assembly, Rear Panel “S”
-
1
8
980651
Washer,
5
/
16
Flat
11
11
9
920110
Nut,
5
/
16
-18 ESNA
4
4
10
980652
Washer,
5
/
16
Lock
7
7
11
85811A
Screw,
5
/
16
-18 x ¾
7
7
12
10129A
Assembly, Squeegee 32”
1
1
13
10075A
Assembly, Squeegee Lift
1
1
14
10069A
Assembly, Traverse System “L”
1
-
10070A
Assembly, Non-Traverse System “S”
-
1
15
980982
Washer #10
2
2
16
10071A
Assembly, Brush Head “L”
1
-
10061A
Assembly, Brush Head “S”
-
1
17
81105A
Nut,
3
/
8
-16 ESNA
4
4
18
87031A
Washer,
3
/
8
Flat SS
4
4
19
50965A
Hinge
1
1
20
85395A
Screw, ¼-20 x
1
/
2
SS
6
6
21
30059A
Front Cover
1
1
22
50966A
Latch, Front Cover
Ref
Ref
23
930090
Rivet,
5
/
32
x
9
/
16
2
2
24
10063A
Assembly, Solution Tank
1
1
25*
Page 12
Battery
871334
Battery 12V, 195 AH (wet - UT Post)
-
2
871335
Battery 12V, 195 AH (dry - UT Post)
-
2
40136A
Battery 6V, 250 AH (wet - Stud Post)
4
4
40137A
Battery 6V, 250 AH (dry - Stud Post)
4
4
891384
Battery, 6V 330 AH (wet - UT Post)
4
4
891385
Battery, 6V 330 AH (dry - UT Post)
4
4
26
41206A
Series Battery Cable (Taper Style)
3
3
41217A
Series Battery Cable (Ring Style)
3
3
27
980205
Washer,
5
/
16
Fender
4
4
28
85734A
Screw,
5
/
16
-18 x 2
2
2
29
85739A
Screw,
5
/
16
-18 x 3 Hex
2
2
30
87026A
Washer, ¼ flat SS
5
5
31
41211A
Battery, Cable (Taper Style)
1
1
40174A
Battery, Cable (Ring Style)
1
1
32
85518A
Screw, ¼-20 x
3
/
4
5
5
NI
10132A
Lit Kit
1
1
NI
17531A
Pad Driver Assembly
1
-
10140A
Pad Driver Assembly
-
1
NI
40512A
Battery charger
1
1
NI
77092A
Label, Gases
1
1
NI
77093A
Label, Falling
1
1
NI
70226A
Label, Battery
1
1
NI
30070A
Accessory Bag
1
1
NI
10072A
Parking Brake Assembly "L"
1
-
NI
10073A
Parking Brake Assembly "S"
-
1
* See page 12 for installation.
