CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426
Page -43-
CLARKE TECHNOLOGY Encore S2426/L2426
Squeegee Assembly Parts List 10/00
39" 32"
Ref. #
Part No.
Description
Qty
Qty
1
962720
Screw, ¼-20 x ½ Hex SS
4
4
2
980657
Washer, ¼ Lock
4
4
3
60243A
Bracket, Squeegee Wheel
2
2
4
30049B
Wheel, Squeegee
4
4
5
81104A
Nut, ¼-20
2
2
6
60254A
Bolt, Shoulder
5
/
16
x 2¼
2
2
7
50958A
Ring,
3
/
8
ID Snap
2
2
8
30048A
Wheel, Guide, 4 Inch Diameter
2
2
9
60272A
Channel, Squeegee Weldment 39”
1
-
60234A
Channel, Squeegee Weldment 32”
-
1
10
50835A
Latch, Squeegee Clamp
1
1
11
930086
Rivet, 3/16 x .450 Aluminum
2
2
12
60252A
Strap, Clamp, Squeegee Retainer 39”
1
-
60232A
Strap, Clamp, Squeegee Retainer 32
-
1
13
30069A
Blade, Rear, Gum Rubber, 39”
1
-
30067A
Blade, Rear, Gum Rubber, 32”
-
1
14
30058A
Spacer, Squeegee 39”
1
-
30047A
Spacer, Squeegee 32
-
1
15
30091A
Blade, Front Ribbed 39”
1
-
30066A
Blade, Front Ribbed 32”
-
1
16
80011A
Screw,
3
/
8
-16 x 3
2
2
17
81301A
Nut,
3
/
8
-16 Jam SS
2
2
18
34260B
Gasket
1
1
19
25201A
Knob
2
2
20
60358A
Shim, Squeegee Wheel
2
2
10068A
10129A
