CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426 Page -37-
CLARKE TECHNOLOGY
Encore S2426/L2426
Rear Panel Assembly Parts List 5/01
Ref. # Part No. Description Qty Qty
L S
1 920224 Nut, 10-32 2 -
2 980603 Washer, Starlock 4 2
3 920056 Nut, 6-32 5 4
4 46106A Rectifier 1 -
5 40133A Harness, Power “L” 1 -
40134A Harness, Power “S” - 1
6 962212 Screw, 6-32 x 7/8 3 2
7 85383A Screw, 10-32 x ¾ 1 -
8 41810A Solenoid, Brush 1 1
9 85395A Screw, ¼-20 x ½ 6 6
10 980614 Washer, Starlock, ¼ 10 10
11 85391A Screw, ¼-20 x 5/8 4 4
12 60261A Panel, Rear Metal 1 1
13 60257A Cable, Squeegee Lift 1 1
14 920346 Nut, Pal 1 1
15 80028A Bolt, Shoulder, 5/16 x 1.0 1 1
16 980692 Washer, Flat 5/16 SS 2 2
17 438360 Spring 1 1
18 64901A Lever, Squeegee Lift 1 1
19 64490A Handle, Squeegee 1 1
20 980666 Washer, 3/8 Starlock 1 1
21 85389A Screw, 3/8-16 x 5/8 1 1
22 68643A Plate, Vacuum Wear 1 1
23 962968 Screw, 10-24 x ½ 2 2
24 61260A Plate, Squeegee Lift 1 1
25 47374A Switch, Vacuum Lever 1 1
26 85601A Screw, 6-32 x 1¼ PN 2 2
27 81217A Nut, ¼-20 x .218H Nylock 1 1
28 60264A Bracket, Power Connector 1 1
29 41146A Cable, Assembly Console 1 1
30 193951 Grommet, slotted, 8” Ref Ref
31 41811A Solenoid, Main 1 -
41810A Solenoid, Main - 1
32 40157A Harness, Traverse 1 -
33 40169A Solenoid, Vacuum 1 1
34 962798 Screw, 10-24 x ½ 4 2
35 40132A Control, Traverse 1 -
36 14097A Low voltage Shutoff - 1
37 30097A Insulator, Mylar 1 1
NI 77093A Label, Falling Parts 1 1
NI 77092A Label, Gases 1 1
NI 47809A 3/8 Ring Terminal, 14-16 - 1
NI 911933 #10 Ring Terminal, 14-16 - 1
NI 40519A Ring Terminal, 5/16 - 1
