CM2 Installation Instructions
22
CM2 Hardware Reference
Motor Control Hardware Information
(See figure 32)
RS485 Network Programmable Paramaters and Status Bit Assignments
RS485 Network Programmable Parameters
Parameter
Identifier
Name Range Factory Default Units
0 Custom Code 1-32687 0 -
1 Maximum Movement Time 100-6000 3100 0.01 sec
2 Extend Speed 1-100 100 %
3 Retract Speed 1-100 100 %
4 Ramp UP Time 10-100 100 0.01 sec
5 Ramp DOWN Time 10-100 100 0.01 sec
6 Show Extend Delay 31-300 100 1 sec
7 Show Retract Delay 31-300 100 1 sec
RS485 Network Status Bit Assignments
Bit Name Bit Location
0 At Home Position - - - - - - - - - - - - - - - X
1 Move in Progress - - - - - - - - - - - - - - X -
2 Network Operation in Progress - - - - - - - - - - - - - X - -
3 Parameter Write Operations Enabled - - - - - - - - - - - - X - - -
4 Network Command Error - - - - - - - - - - - X - - - -
8 At Extend Limit - - - - - - - X - - - - - - - -
9 At Retract Limit - - - - - - X - - - - - - - - -
