20 • Telescope Basics
T E L E S C O P E B A S I C S
Once your telescope has been fully assembled and the accessories attached,
you are ready to take a look. This section deals with basic telescope operation.
The Newtonian optical system produces an upside down image. This will
only affect your terrestrial observations. For celestial viewing, star charts can
be made to match the view in the telescope by rotating the chart 180° about the
center. The view through the finder is also inverted.
Image Orientation
Actual Veiw
Newtonian View
Figure 3-1
The figure illustrate the image orientation of the G-8N. Top is the actual orientation
while below is the image seen through the G-8N. The finderscope produces an inverted
(upside-down and backwards)image.
