Item # 67402, Model NJL-2323 NJL-Series Quicher Series Interchangeable Rail Screw Presenter
QUOTE
Model NJL-2323 NJL-Series Quicher Series Interchangeable Rail Screw
Presenter
"Quicher" Series
• Simple operation
• Pick-up rate of up to two screws per second
• Screws are poured into hopper and automatically lined up
• Flat, horizontal rail design eliminates screw "jams"
• 220V available
NJL Model
• Feeds screws up to 25 mm long
• Same physical structure as the NJ models
• 220V available
Interchangeable Rail Screw Presenters
• Accommodates wide variety of screw sizes by plugging in interchangeable rails
• Handles #000 to #10 screws; even with washers
• Doesn't require multiple dedicated-size feeders
• Models for robotic applications available.
Contact ASG.
Note! Each model is supplied with the rail listed as standard equipment.
· SPECIFICATIONS · CLASSIFICATION · WORKABLE RANGE
SPECIFICATIONS
Units Per Package
1
Width
5 1/4 in
Depth
8 1/2 in
Model No.
NJL-2323
Screw Size
2.3 mm
#2 in
Max. Screw Dia. 1
0.0984 in
Length
1 in
25.4 mm
Weight
7 lb
Screw Feeding Speed
2 Screw per second
