Item # 64004, Model HDP-5 QC Auditing Tester
QUOTE
HDP-Series
• Comes with certificate of calibration traceable to N.I.S.T.
• Find the failure point for fasteners
• Find the failure point for the hole
• Audible warning tone can be set to warn operator when desired torque is approached
• Max, Min and Avg given of last 10 readings
• Analog or data signal in Mitutoyo format
• Optional adaptor and cable needed to connect to PC.
• Runs on rechargeable Ni-MH batteries
• Comes complete with aluminum carrying case, rechargeable battery (installed), and battery charger.
• 220V available
• Measure removal torque of fasteners, bottle caps or other container
• Measure shear strength
• Measure material strength
• Measure removal torque
• Calibrate tools
• 100 reading memory
• Max, Min &Avg Readings
• Data output for SPC
· SPECIFICATIONS · CLASSIFICATION
SPECIFICATIONS
Units Per Package
1
Model No.
HDP-5
Torque 1
0.15 to 4.40 lbf·in
0.015 to 0.500 N·m
Size
4.9 x 3.8 x 1.5 in
Weight
1.7 lb
Battery
1.2V NiMH cell x 5
Charging Time
Up to 6 hrs
Lifetime per Charge
8 hrs
ESD Safe
No
1 Units that read out in kgf·cm available as special order
