Item # 66134, EZ-870 Carousel Tape Dispenser
QUOTE
EZ-870 Carousel Tape Dispenser
• Provides consistent lengths from 15 mm to 70 mm with easily adjustable tape length and spacing
• Cuts tape and places it on carousel at the push of a button, accommodating multiple operators
• Bobbin-free design accommodates any size coreAccepts many types of tape, including filament, polyimide, acetate
cloth, glass cloth, double-sided, plastic, aluminum foil, cellophane, masking, Nomex®, copper, cloth, polyethylene, PTFE,
paper, craft, OPP, polyimide (Kapton®) and more
• 220V available
·
SPECIFICATIONS
·
CLASSIFICATION
SPECIFICATIONS
Units Per Package
1
Model No.
EZ-870
Accuracy of Cut
±0.08 in
2 mm
Size
4.96 x 5.91 x 10.16 in
126 x 150 x 258 mm
Tape Width
0.1118 to .984 in
3 to 25 mm
Cut Length
0.59 to 2.76 in
15 to 70 mm
Max. Outside Dia. Tape Roll
5.91 in
150 mm
Auto Feed
Yes
Electrical Requirements
120 V
