Item # 64034, Model HM-100 Automated or Robotic Tester
QUOTE
Model HM-100 Automated or Robotic Tester
HM-Series
• Comes with certificate of calibration traceable to N.I.S.T.
• Easy calibration of screwdriver without removing from machine
• Analog or data signal in Mitutoyo format
• Reads torque clockwise or counterclockwise with equal accuracy
• Runs on rechargeable NiCd batteries
• Comes complete with aluminum carrying case, rechargeable battery (installed), battery charger and screwdriver
adaptor.
• 220V available
• Test screwdrivers used in autofeeders, robots or built into assembly machines
• Separate transducer
• On-the-spot calibration
• Data output for SPC
·
SPECIFICATIONS
·
CLASSIFICATION
SPECIFICATIONS
Units Per Package
1
Model No.
HM-100
Torque
1.5 to 90.00 lbf·in
0.15 to 10.00 N·m
1.5 to 100.0 kgf·cm
Supplied With Adaptor Part. No.
64045, Accessories for HIOS® HM-Series Digital Torque Testers for Automated or Robotic Applications
Size
5.7 x 6.6 x 3 in
Weight
1.8 lb
Battery
1.2V NiCd cell x 5
Charging Time
12 hrs
Lifetime per Charge
30 hrs at full charge
ESD Safe
No
