FIAM TOM Control Unit
0% Error - 100% Accuracy. The FIAM TOM System (Tightening Operation Monitor) is an intelligent and simple process
monitoring system designed for use with Fiam pneumatic screwdrivers. A single system can manage up to eight
different Fiam 2CS auto shut-off tools equipped dual pneumatic pick-up signal ports. Poka-Yoke system allows users to
set torque and speed of a single or sequential program. Each program can monitor up to 99 fasteners. Time-Off feature
briefly deactivates the tool after OK signal is received to avoid 'double hit' operator errors.
TOM Control Unit includes power cord as standard.
REQUIRED COMPONENTS (purchased separately) required for a complete TOM System:
BASIC SINGLE TOOL MONITORING
• TOM Control Unit (TOM 06F0864, #685001062)
• Transducer Kit (6F0866, #685001068)
PREMIUM SINGLE TOOL MONITORING 15C/26C TOOLS
• TOM Control Unit (TOM 06F0864, #685001062)
• Transducer Kit (6F0866, #685001068)
• Tool Locking/Unlocking Device for 15C/26C (6F0867, #685001069)
• Connector Cable TOM Control Unit to Tool Locking/Unlocking Device (6F0876, #685001071)
PREMIUM SINGLE TOOL MONITORING AD/AG/CY TOOLS
• TOM Control Unit (TOM 06F0864, #685001062)
• Transducer Kit (6F0866, #685001068)
• Tool Locking/Unlocking Device for AD/AG/CY (6F0878, #685001070)
• Connector Cable TOM Control Unit to Tool Locking/Unlocking Device (6F0876, #685001071)
MULTIPLE TOOL MONITORING
• TOM Control Unit (TOM 06F0864, #685001062)
• Multi-Dock Connector (6F0865, #65001065)
• Transducer Kits (One per tool up to 8) (6F0866, #685001068)
• Tool Locking/Unlocking Devices (One per tool up to 8) (6F0867 #650001069 - For 15C/26C Tools) (6F0878
#685001070 - For AD/AG/CY Tools)
• Connector Cables (One per tool up to 8) - TOM Multi-Dock to Tool Locking/Unlocking Device (06F0870 #685001072)
