Dodge 2014 Charger - Police Supplement User Manual
Page 13
Figure 3 - Passenger Air Bag Deployment Zone, depicts
the following.
1. Passenger Air Bag Cushion
2. Vertical Plane from Point of Instrument Panel
3. Passenger Air Bag Module
4. Instrument Panel
5. Vertical Plane Passing Through the Maximum Rear-
ward Point that the Passenger Air Bag Cushion
Reaches
6. 18.5 inches (47 cm)
Figure 3
12
