Figure 1 - Driver Air Bag Deployment Zone, depicts the
following.
1. Vertical Plane Passing Through Center of Steering
Wheel
2. 18.5 inches (47 cm)
3. Vertical Plane Passing Through Maximum Rearward
Point that the Driver Air Bag Cushion Reaches
4. Steering Wheel
5. Driver Air Bag Retainer/Housing
6. Driver Air Bag Cushion
DRIVER AIR BAG/STEERING COLUMN SPECIFI-
CATIONS
DRIVER AIR BAG CUSHION POSITION
DAB Diameter When
Deployed (Full)
26.5 inches (67 cm)
DAB Depth When
Deployed (Full)
15 inches (38 cm)
Maximum Rearward
Displacement During
Deployment (Fill)
18.5 inches (47 cm)
STEERING COLUMN TILT POSITION RANGE
+/– 2.7 Degrees from Steering Column Tilt Pivot
Point
21.0 Degrees from Vertical is the Nominal Position
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
