Page 22
22
DV360/580 Series Direct Vent Gas Fireplace
20010667
FP1184
Typical roof/ceiling
support apps.
Typical Roof
Support
Application
Typical Ceiling
Support
Application
FP1184
Fig. 43 Venting supports.
Min.
2' (610 mm)
FP1185
Fig. 44 Minimum termination to roof clearance.
TWL101a
Twist Lock Pipe
2/8/99 djt
3 #5 Sheet Metal
Screws per Joint
Sealant
Storm Collar
TWL101a
Fig. 45 Roof flashing.
