DBS Processor Page 2
SECTION II
PROCESSOR OVERVIEW
A. Hardware
Part Name Part #
Peripheral Equipment
footswitch (1) ................................842-6091
computer cables (1) ......................83F888
AC line cord (1) ............................ELC-1009
Barcode
Hand held scanner (1) ....................LS1006-I000-1900Z
Punch and Die
die plate (1) ...................................A1578
punch (1) .......................................A2431
punch holder (1)…………………..A2430
X-Y Stage
lead screw shaft (2) .......................SPM4-3708-10.4375
lead screw nut (2) .........................TAB4-3708M
brg support unit (2) .......................B6-01
linear guide (4) .............................SR20V2UU+280L-II
Electrical
photosensor (6) .............................EE-SX671
limit switch (1) .............................ELC-1025
indexer/driver (2) ..........................IM483I
driver power supply (1) ................IP404
I/O power supply (1) .....................800-9756
rocker switch (1) ...........................ELC-1019
fuse (1) ..........................................10 amp
fuse (1) ...........................................2 amp
fuse (1) ...........................................3 amp
motor……………………………..M2-2220-S
interface board……………………OTP4-232
