NISSAN 2013 Murano - Quick Reference Guide - Manual (Page 10)

FRONT SEAT ADJUSTMENTS
MANUAL SEATS (if so equipped)
To slide the seat forward or backward, pull up on
the lever 01 under the front of the seat and slide
forward or backward. Release the lever to lock the
seat in position.
To adjust your seatback forward or backward, lift the
lever
02 on the side of the seat.
Release the lever when you have found a comfortable
angle and the seat belt fi ts properly.
SEAT LIFTER (if so equipped)
To adjust the seat height, pull up or push down on
the adjusting lever 03 repeatedly.
LUMBAR SUPPORT (if so equipped)
Your driver’s seat lumbar support 04 is located on
the inboard side of the driver’s front seat.
Adjust by moving the lever up or down.
8
f i r s t d r i v e f e a t u r e s
SOFT TOP OPERATION (CrossCabriolet models)
The soft top can be operated only when the trunk is
separated by the luggage cover. The luggage cover must
be pulled out and hung on both hooks or the top will not
operate. Before opening or closing your soft top, refer to
the Owner’s Manual for detailed warnings and cautions
regarding soft top operation.
Soft Top Operation
1. Make sure the area around the vehicle is clear of obstructions and that there is more
than 10 feet (3 m) of clearance from the ground and more than 4.9 feet (1.5 m) of
clearance from the rear of the vehicle.
2. Pull out the luggage cover and hang on both hooks 01
.
3. Apply the parking brake and move the shift lever to the P (PARK) position.
4. Depress the brake pedal.
5. Start the engine.
6. Push and hold the soft top operating switch, located
on the center console, to OPEN 02
or CLOSE
03
until the top is fully opened or closed.
For more information, refer to the “Instruments and controls (section 2)”
and the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
02
03
01
01
02
03
04
P
S
L
F
O
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
