To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

• Connect the charge connector

to the charge port

A beep will sound once.

• If plugging in the EVSE connector to a power outlet,

attach a string to the control box

and hang on a hook

near the outlet, or set on a suitable surface off the ground.

To stop charging:
• Press the button

on the charge connector to release the

lock and remove the charge connector from the charge port.

• Close the charge port cap and the charge port lid.
• Remove the EVSE plug from the power outlet, attach the

safety cap to the charge connector and store in the case.

QUICK CHARGE (if so equipped)

Perform a quick charge by connecting the charge connector
of a quick charger at a charge station to the vehicle.

It takes approximately 30 minutes to charge the

Li-ion battery to 80% when the low battery charge
warning light illuminates.

To charge your vehicle:
• Place the power switch in the OFF position.
• Open the charge port lid by pushing the charge

port lid opener switch located on the instrument
panel to the left of the steering wheel and unlatch the charge port cap

• Align the groove of the charge connector with the groove of the charge port, then insert

the charge connector.

• Grasp the lock lever and then lock the charge connector.
• Follow the instructions on the quick charge equipment to start charging. When the

equipment is properly installed and ready to charge, a beep sounds twice and the
charging status indicator light will change.

To stop charging:
• Follow the instructions on the quick charge equipment.
• Unlock the charge connector and remove it from the vehicle.
• After closing the charge port cap, close the charge port lid.

For more information, refer to the “EV overview (section EV)” and the “Charging (section CH)” of your Owner’s Manual.
