TRANSFER CASE SHIFTING
PROCEDURES
All mode 4WD system provides 4 positions
(AUTO, 2WD, 4H and 4LO), so you can select
the desired drive mode according to the driving
conditions.
2WD or 4WD shift procedure:
4WD Shift
Switch Position
Wheels Driven
Indicator Light
Use Conditions 4WD Shift Procedure
4WD shift Transfer 4LO position
AUTO
Rear wheels or 4
wheels For driving on paved or slippery
roads
Move the 4WD switch.
2WD <—> AUTO <—> 4H
4WD shift indicator light will indicate transfer shift po-
sition engaged.
IT IS NOT NECESSARY TO MOVE THE SHIFT SE-
LECTOR TO THE N POSITION IN THIS OPERATION.
PERFORM THIS OPERATION WHEN DRIVING
STRAIGHT.
2WD
Rear wheels
For driving on dry, paved roads
(Economy drive)
4H
4 wheels
For driving on rocky, sandy or snow-
covered roads
Neutral
*1
May blink
Neutral disengages the automatic
transmission mechanical parking
lock, which will allow the vehicle to
roll. Do not leave the transfer shift
position in Neutral.*2 1. Stop the vehicle.
2. Move the shift selector to the N position.
3. Push the 4WD shift switch and move it to 4LO or
4H with the brake pedal depressed.
YOU CANNOT MOVE THE TRANSFER 4WD SHIFT
SWITCH BETWEEN 4H AND 4LO (OR 4LO TO 4H)
UNLESS YOU HAVE FIRST STOPPED THE VE-
HICLE, DEPRESSED THE BRAKE PEDAL AND
MOVED THE SHIFT SELECTOR TO NEUTRAL. *3 4LO
4 wheels
Illuminated
For use when maximum power and
traction is required (for example: on
steep grades or rocky, sandy, muddy
roads)
5-24 Starting and driving
