ZX2 coupe instrument cluster
Low fuel
Illuminates when the fuel tank has
approximately eight liters (two
gallons) remaining. The lamp will
also illuminate when the ignition
key is turned to ON and the engine
is off.
Service engine soon
Your vehicle is equipped with a
computer that monitors the
engine’s emission control system.
This system is commonly known as
the On Board Diagnostics System
(OBD II). This OBD II system
protects the environment by
ensuring that your vehicle
continues to meet government
emission standards. The OBD II
system also assists the service
technician in properly servicing
your vehicle.
The Service Engine Soon
indicator light illuminates when the
ignition is first turned to the ON
!
THEFT
LOW
FUEL
CHECK
COOLANT
SERVICE
ENGINE
SOON
P
BRAKE ABS + –
MPH
20
50
60 70
FUEL
FILL
E F C H
1 2 /
RPMx1000
1
2
3
4 5
6
7
8
30
40
80
90
100
110
120 10 20
40
60
80
100 120
140
160
180
km/h
0
0
0 0 0 0 0
0 0 0
LOW
FUEL
SERVICE
ENGINE
SOON
Instrumentation
