Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
12 60A** Engine Compartment Fuses 25,
27
13 50A** Blower Motor Relay (Blower
Motor)
14 30A** Trailer Running Lamps Relay,
Trailer Backup Lamps Relay
15 40A** Main Light Switch, Daytime
Running Lights (DRL)
16 50A** Auxiliary Blower Motor Relay
17 30A** Fuel Pump Relay
18 60A** I/P Fuses 40, 41,26, 33, 39
19 60A** 4WABS Module
20 20A** Electric Brake Controller
21 50A** Modified Vehicle Power
22 40A** Trailer Battery Charge Relay,
Modified Vehicles
23 60A** Ignition Switch, Fuse Panel
24 20A* Natural Gas Tank Valves (NGV
only)
25 20A* NGV Module (Natural Gas Only)
26 10A* A/C Clutch (4.2L Only)
27 15A* DRL Module, Horn Relay
28 — PCM Diode
29 — Not Used
A — Not Used
B — Stop Lamp Relay
C — Trailer Backup Lamps Relay
D — Trailer Running Lamps Relay
E — Trailer Battery Charge Relay
F — IDM Relay (Diesel Only), A/C
Clutch Relay (4.2L Only)
G — PCM Relay
Roadside emergencies
183
