Passenger compartment fuse panel
The fuse panel is located below and to the left of the steering wheel by
the brake pedal. Remove the panel cover to access the fuses.
To remove a fuse use the fuse puller tool provided on the fuse panel
cover.
The fuses are coded as follows.
Fuse/ Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
1
20A
4WABS Module
2
15A
Brake Warning Lamp, Instrument
Cluster, Warning Chime, 4WABS
Relay, Warning Indicators, Low
Vacuum Warning Switch (Diesel
Only)
1
2
3
4
5
7
6
8
9
10
11
42
43
44
13
12
14
15
16
17
19
18
20
21
22
23
25
24
26
27
28
29
31
30
32
33
34
35
37
36
38
39
40
41
