Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse Panel
Description
11 15A Electric brake controller, Brake shift interlock
solenoid, Rear electronic module
12 20A Center high-mounted stop lamp
13 10A Right rear turn lamp, Left stop lamp, Left rear
park lamp
14 10A Autolamp sensor, Transmission overdrive
cancel switch, Front electronic module,
Compass module, Electrochromatic mirror,
PSD overhead console switch
15 20A Console power point
16 10A Cluster
17 20A Cigar lighter/Powerpoint, Datalink connector
18 15A Quarter Window Motors, RH window switch
backlighting, RH lock switch backlighting,
Master control switch (LH) backlighting,
Radio, VCP, Liquid Crystal Display (LCD),
Front electronic module
19 10A Starter interrupt relay (coil)
20 — Not used
21 — Not used
22 10A Heated Mirrors
23 20A Body power point, Auxiliary blower relay #1
and #2 coils
24 — Not used
25 10A Radio (Anti-theft)
26 10A Air bag module, Passenger air bag deactivated
indicator, Passenger seat weight pressure
sensor ECU
27 — Not used
28 10A Cluster
29 2A Speed control deactivation switch
Relay 1 — Switched system power relay #4
Roadside Emergencies
158
