Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
13 30A** Primary Fuel Pump Delivery
Module (FPDM), Secondary Fuel
Pump Delivery Module (FPDM)
14 30A** Intercooler pump
15 20A* Alternator field circuit
16 5A* EEC keep alive power
17 25A* Lighting (Left headlamp)
18 25A* Lighting (Right headlamp)
19 20A* Fog lamps
20 20A* Anti-lock Brake System (ABS)
module
21 10A* A/C clutch coil
22 20A* Power point
23 Full ISO relay High-speed fan #2
24 Full ISO relay Low-speed fan
25 Full ISO relay PCM
26 Full ISO relay High-speed fan #1
27 20A* Injector
28 15A* HEGO sensors
29 15A* PCM power: PCM, Mass Air Flows
(MAF) sensor/IAT sensor, BFIM,
VMV, CVS, SCBS, Exhaust Gas
Recirculation (EGR) valve, Idle
Air Control (IAC)
30 1 ⁄
2
ISO relay Supercharger intercooler
31 1 ⁄
2
ISO relay Right headlamp
32 1 ⁄
2
ISO relay Left headlamp
* Mini fuse **Cartridge fuse
2005 GT (gto)
Owners Guide (post-2002-fmt)
USA_English (fus)
Roadside Emergencies
113
