Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
R24 — Not used
R25 — Rear defrost/Heated mirror relay
30 10A Parking lamps
31 20A Radio
32 15A Turn signal (GEM)
33 20A Sunroof
34 20A Horn
35 7.5A A/C switch, Instrument cluster
36 7.5A Interior lamps, Power mirrors
37 — Not used
38 — Not used
39 2A PCM relay coil
40 25A Rear defroster
41 — Not used
42 10A Stop lamps, Shift interlock
43 15A Rear wiper, Sunroof (ignition)
44 15A Daytime Running Lamps (DRL)
45 7.5A Recirculated air, Air conditioning
46 — Not used
47 20A Cigar lighter/Power point
48 10A Data link connector
49 7.5A Heated mirror, Heated backlite
indicator
50 10A Back- up lamps (automatic
transaxle only)
51 7.5A Front passenger sensing system
52 15A Heated seats
53 10A Back-up lamps (manual transaxle
only), Speed control
54 25A Rear power windows
55 25A Front power windows
2007 Focus (foc)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
147
